Briggs Stratton 3864 Vanguard – V-Twin 23HP Small Engine (Horizontal)
$977.00
The Briggs & Stratton Vanguard 3864 is a 23HP 627cc V-Twin horizontal shaft engine designed for industrial and commercial applications. It delivers strong torque, smooth performance, and long-lasting durability for continuous-duty operation in demanding work environments.
In Stock
Description
Briggs & Stratton 3864 Vanguard – 23HP V-Twin Horizontal Shaft Engine
Description: Premium commercial-grade V-Twin horizontal shaft engine designed for industrial, agricultural, and heavy-duty equipment applications. Built to deliver exceptional torque, reliable power, and long service life under continuous operating conditions.
The Briggs & Stratton Vanguard 3864 is a 23HP V-Twin horizontal shaft engine engineered for demanding commercial and industrial applications. Featuring a 627cc OHV V-Twin design, this engine provides smooth power delivery, outstanding low-end torque, and dependable performance for equipment operating under heavy workloads.
As part of the renowned Vanguard commercial engine series, the 3864 is built with professional-grade components including cast-iron cylinder sleeves, full-pressure lubrication, spin-on oil filtration, dual-element air filtration, and electronic ignition. These features help maximize engine durability, improve protection against wear, and ensure reliable operation in harsh environments.
The Vanguard 3864 is commonly used in industrial generators, hydraulic power units, pressure washers, pumps, construction equipment, and agricultural machinery, where continuous-duty performance and reliability are critical.
Key Features
- 23HP commercial-grade power output
- 627cc OHV V-Twin engine for high torque performance
- Smooth operation with reduced vibration
- Cast-iron cylinder sleeves for extended engine life
- Full-pressure lubrication system with oil filter
- Heavy-duty dual-element air filtration
- Electric start for convenient operation
- Built for continuous-duty commercial applications
- Durable construction for demanding environments
- Ideal for industrial, agricultural, and utility equipment
Applications
- Industrial generators
- Hydraulic power units
- Pressure washers
- Water pumps
- Construction equipment
- Agricultural machinery
- Utility and commercial equipment
| Specification | Details |
|---|---|
| Brand | Briggs & Stratton |
| Model | 3864 |
| Series | Vanguard |
| Engine Type | 4-Stroke OHV V-Twin Horizontal Shaft |
| Displacement | 627cc |
| Horsepower | 23 HP |
| Cylinder Configuration | V-Twin |
| Shaft Orientation | Horizontal |
| Fuel Type | Gasoline |
| Starting System | Electric Start |
| Cooling System | Air-Cooled |
| Fuel System | Carburetor |
| Ignition System | Electronic Ignition |
| Lubrication | Full Pressure Lubrication |
| Oil Filter | Spin-On Full-Flow Filter |
| Air Filtration | Heavy-Duty Dual-Element Air Cleaner |
| Cylinder Liners | Cast Iron |
| Maximum RPM | 3600 RPM |
| Application | Industrial / Commercial Equipment |
