Generac 6797 Electric Diaphragm Pump (1800 GPH, 2in, Single Phase)
$933.00
The Generac 6797 Electric Diaphragm Pump delivers up to 1,800 GPH (30 GPM) with a 2-inch port and single-phase electric motor. Designed for pumping dirty water, sludge, and debris, it features a durable diaphragm system, dry-run capability, and reliable performance for construction and dewatering applications.
In Stock
2-Day Shipping
|
All orders are processed and dispatched within 2 days
Description
Generac 6797 Electric Diaphragm Pump (1800 GPH, 2in, Single Phase)
The Generac 6797 Electric Diaphragm Pump is a heavy-duty 2-inch utility diaphragm pump designed for reliable dewatering in construction, agriculture, and emergency water removal applications. Built with a rugged diaphragm pumping system, it is capable of handling dirty water, sludge, sand, and debris-laden fluids without the impeller damage issues found in conventional centrifugal pumps.
With a flow capacity of up to 1,800 GPH (30 GPM), this pump is ideal for shallow water removal, trench dewatering, foundation work, and flood cleanup. Its electric single-phase motor design provides quiet operation, low maintenance requirements, and consistent performance for continuous-duty use.
Unlike standard water pumps, the diaphragm design allows the unit to run dry without damage, making it highly reliable in intermittent water conditions commonly found on construction sites and disaster recovery environments.
Key Features
- Handles dirty water, mud, and debris without clogging
- Diaphragm system eliminates impeller damage risks
- High flow capacity up to 1,800 GPH
- Safe dry-run capability without pump damage
- Electric motor for quiet and low-maintenance operation
- Self-priming design for easy startup
- Durable construction for job site use
- Ideal for continuous or intermittent dewatering
- Reliable performance in harsh environments
- Designed for construction, utility, and emergency applications
Applications
- Construction site dewatering
- Foundation and trench drainage
- Flood water removal
- Muddy or debris-filled water pumping
- Utility maintenance projects
- Agricultural water transfer
- Emergency and disaster cleanup
- Basement and confined-space dewatering
| Specification | Details |
|---|---|
| Model | 6797 |
| Brand | Generac |
| Pump Type | Electric Diaphragm Pump |
| Inlet / Outlet Size | 2 in (50.8 mm) |
| Maximum Flow Rate | 1,800 GPH (30 GPM) |
| Motor Type | Single-phase electric motor |
| Power Source | Electric (corded) |
| Voltage | 110–120V / 230V (varies by configuration) |
| Pump Technology | Positive displacement diaphragm system |
| Self-Priming | Yes |
| Dry-Run Capability | Yes (no damage when running dry) |
| Solids Handling | Sand, sludge, mud, and debris tolerant |
| Pump Housing | Heavy-duty corrosion-resistant construction |
| Portability | Portable skid-mounted design |
| Maintenance | Low maintenance, easy service design |
| Application Class | Light to medium-duty dewatering |
