Chicago Pneumatic RCP-1630G Air Compressor – 16HP Gasoline
$2,677.00
Chicago Pneumatic RCP-1630G Air Compressor: High-output 16HP gasoline-powered service truck compressor featuring a Vanguard engine, designed to deliver professional-grade pneumatic power in remote field locations.
- Engine Specs: 16.0 HP Briggs & Stratton Vanguard
- Pneumatic Supply: 991 L/min (35.0 CFM)
- Maximum Force: 175 PSI (12 Bar)
- Tank Dimension: 30 Gallon Horizontal
- Technical Spec: 12V Electric Start & Recoil Backup
In Stock
Description
Chicago Pneumatic RCP-C1630G Air Compressor – 16 HP Gasoline (Iron Series Two-Stage)
The Chicago Pneumatic RCP-C1630G Air Compressor is a heavy-duty gasoline-powered industrial reciprocating compressor designed for mobile job sites, truck-mounted systems, construction work, and remote industrial applications where electrical power is not available. Built on Chicago Pneumatic’s Iron Series cast iron platform, it combines durability, portability, and high airflow performance for professional users.
This unit is powered by a 16 HP Briggs & Stratton Vanguard gasoline engine and paired with a two-stage cast iron compressor pump, mounted on a 30-gallon ASME-certified horizontal tank. It delivers approximately 35 CFM at 100 PSI (about 32–35 CFM at 175 PSI depending on load conditions), making it suitable for demanding pneumatic tools in field environments.
Key Features
- 16 HP Briggs & Stratton Vanguard gasoline engine
- Heavy-duty two-stage cast iron compressor pump
- Air delivery: ~35 CFM @ 100 PSI
- Maximum pressure: 175 PSI
- 30-gallon ASME-certified horizontal air receiver tank
- Electric start + recoil start system
- Fully enclosed belt guard for safety
- Engine slowdown (pilot valve) for fuel efficiency
- Oil level monitoring system
- Built for truck mount and mobile service applications
Performance Overview
The RCP-C1630G is designed for off-grid compressed air applications, where reliability and mobility are more important than stationary capacity. The low-RPM cast iron pump improves durability and helps maintain consistent performance under harsh working conditions.
Its key strengths include:
- High portability for mobile service trucks
- Strong airflow for pneumatic tools and blasting equipment
- Engine-driven independence from electrical supply
- Durable cast iron construction for long service life
It is commonly used in environments such as:
- Roadside service and fleet maintenance
- Construction and civil engineering sites
- Sandblasting and surface preparation
- Mobile repair units
- Remote industrial maintenance work
Iron Series Advantages
Mobile Power Independence
Gasoline engine allows operation anywhere without electrical infrastructure.
Cast Iron Durability
Two-stage pump design ensures long lifespan under continuous heavy load.
Service-Friendly Design
Accessible components simplify maintenance in field conditions.
High Output for Portable Class
Delivers strong airflow suitable for demanding pneumatic tools.
Ideal Applications
- Construction sites
- Mobile service trucks
- Industrial field maintenance
- Sandblasting operations
- Remote job sites
- Utility and infrastructure work
| Specification | Details |
|---|---|
| Model | Chicago Pneumatic RCP-C1630G |
| Series | Iron Series Gas Drive |
| Engine | 16 HP Briggs & Stratton Vanguard |
| Compressor Type | Two-Stage Cast Iron Piston |
| Fuel Type | Gasoline |
| Air Delivery | ~35 CFM @ 100 PSI |
| Maximum Pressure | 175 PSI |
| Tank Capacity | 30 Gallons |
| Tank Orientation | Horizontal |
| Start System | Electric + Recoil Start |
| Duty Cycle | Heavy-Duty / Mobile Industrial Use |
| Application | Field / Truck Mount / Construction |
