Champion HR30D-24 Air Compressor – 30HP R-Series
$15,400.00
The HR30-24 is designed for facilities that need plant-wide compressed air distribution rather than localized shop use. Its R-70 pump platform is optimized for low RPM operation, which improves long-term durability by reducing:
- Mechanical stress on bearings and crankshaft
- Heat buildup during continuous operation
- Vibration and structural fatigue
- Maintenance frequency over time
The 240-gallon receiver tank provides substantial air storage, helping stabilize pressure during peak demand and reducing compressor cycling. This is especially important in environments where multiple machines draw air simultaneously.
In Stock
Description
Champion HR30-24 Air Compressor – 30 HP R-Series Industrial Two-Stage Air Compressor (240 Gallon)
The Champion HR30-24 Air Compressor is a heavy-duty R-Series industrial reciprocating compressor engineered for large manufacturing plants, automotive production facilities, fabrication workshops, and centralized compressed air systems requiring very high airflow and continuous-duty reliability. It is powered by a 30 HP three-phase electric motor and equipped with Champion’s rugged R-70 two-stage cast iron compressor pump, mounted on a large 240-gallon ASME-certified horizontal air receiver tank.
Designed for high-demand industrial environments, the HR30-24 delivers approximately 200–205 CFM at 175 PSI, making it one of the highest-output single-frame R-Series systems available. This compressor is built for 24/7 operation in multi-shift production facilities where compressed air is critical to uptime and productivity.
Key Features
- 30 HP industrial three-phase electric motor
- Heavy-duty Champion R-70 two-stage cast iron compressor pump
- Air delivery: ~200–205 CFM @ 175 PSI
- Maximum operating pressure: 175 PSI
- Large 240-gallon ASME-certified horizontal air receiver tank
- Low-speed pump design (~907 RPM) for reduced wear and heat
- Splash-lubricated crankcase system for proven reliability
- High-efficiency disc valve technology
- Deep finned intercoolers for improved cooling
- Loadless centrifugal unloading system for safe starting
- Heavy-duty industrial control panel (configuration dependent)
- Continuous-duty operation for demanding environments
R-Series Advantages
Heavy-Duty Cast Iron Construction
Built for long service life under continuous industrial loads.
High Airflow Capacity
Delivers ~200+ CFM, suitable for large-scale production facilities.
Low-Speed Efficiency Design
Approximately 907 RPM operation reduces wear and improves longevity.
Proven Industrial Reliability
Widely used in manufacturing environments where downtime is costly.
Ideal Applications
- Manufacturing plants
- Automotive production facilities
- CNC machining operations
- Metal fabrication workshops
- Industrial maintenance departments
- Packaging and processing plants
- Large assembly lines
- Central compressed air systems
| Specification | Details |
|---|---|
| Model | Champion HR30-24 |
| Series | R-Series |
| Motor Power | 30 HP |
| Pump Model | R-70 |
| Compressor Type | Two-Stage Reciprocating |
| Lubrication | Splash Lubricated |
| Air Delivery | ~203 CFM @ 175 PSI |
| Maximum Pressure | 175 PSI |
| Tank Capacity | 240 Gallons |
| Tank Orientation | Horizontal |
| Pump Speed | ~907 RPM |
| Voltage | 208V / 230V / 460V Three-Phase |
| Duty Cycle | Continuous Industrial Service |
| Application | Heavy Industrial Manufacturing |
